3 sets roof tile machines and 3 sets hydraulic decoiler with coil car to Ecuador as follow:
Zhongyuan’s target is to service for customers who have quality requirements and high-standard sheet.
Roof Tile Roll Forming Machine Main Technical Parameters:
Coil Width: 1220mm
Suitable Coil Thickness: 0.38 - 0.50 mm
Suitable Raw Materials: Color steel coils
Yield strength of raw material: 320MPA (Buyer sends raw material to test the machine before delivery )
Note: Inspect machine with 0.4mm thickness raw material from buyer.
Working Speed: About 5-6m/min. (including the cutting& pressing time)
Main Motor Power: 5.5KW (Depend on final design)
Hydraulic Station Power: 5.5KW (Depend on final design)
Control System: Mitsubishi PLC and transducer (Japan)
Encoder: Nemicon (Japan)
Rollers’ material High grade No.45 forged steel, with digital-controlled procession,
plated wit chrome on surface.
Shaft diameter 72mm, tooled by grinding machine for two times to ensure the precision of final product.
Type of Cutting: Length-set cutting and post forming style
Electric Condition: 460V/3Phase/60HZ
6T hydraulic decoiler with coil car Main Technical Parameters:
Size of 6T hydraulic decoiler:2.6*1.67*1.85m
weight of hydraulic decoiler:1970kgs
Size of coil car:1.66*1.43*0.72m
Weight of coil car:1435kgs
MACHINE COMPONENTS Of Roll Forming Machine:
(1) Hydraulic decoiler 1 set(Capacity: 6tons)
(2) Guiding Equipment 1 set
(3) Covering film device 1 set
(4) Roll Forming Equipment 1 set
(5) Pressing equipment 1 set
(6) Post-cutting Equipment 1 set
(7) Hydraulic Station 1 pc
(8) PLC Control Panel 1 pc
(9) Automatic stacker 1 set (12m length)
(10)Tool Box 1 pc
Pictures of tile machine and 6T hydraulic decoiler with coil car:
